Small body and light weight
High quality Pump
With overload automatic unloading device,
and full-load descending speed limit device
Molded production, moderate price, stable quality;
high-strength polyurethane wheels is stable,
flexible, light, and free of magnetic fields and sparks;
| CBY(NA)/25 Manual pallet truck technical parameters（Okukun Pump，Hopper Pump） | ||||||
| CBY30 | CBY25 | |||||
| 1 | load capacity/rated load | Q | 3000 | 2500 | kg | |
| 2 | Fork overall width | B | 520/685 | 520/685 | mm | |
| 3 | Fork length | L | 1070/1220 | 1070/1220 | mm | |
| 4 | Fork width | e | 150 | 150 | mm | |
| 5 | Lift Height(Min) | h | 80 | 80 | mm | |
| 6 | Lift Height(Max) | h1 | 200 | 200 | mm | |
| 7 | Tyre size (steering wheel) | φ180×65 | φ180×65 | mm | ||
| 8 | Tyre size (Bearing wheel) | Single Wheel | φ78×100 | φ78×100 | mm | |
| 9 | Tyre size (Bearing wheel) | Double Wheel | φ78×70 | φ78×70 | mm | |
| 10 | Weight | 75 | 68 | kg | ||
| CBY(NA)/25 manual pallet truck technical parameters（Okukun Low chassis of Pump，Hopper Pump） | ||||||
| CBY30 | CBY25 | |||||
| 1 | load capacity/rated load | Q | 3000 | 2500 | kg | |
| 2 | Fork overall width | B | 520/685 | 520/685 | mm | |
| 3 | Fork length | L | 1070/1220 | 1070/1220 | mm | |
| 4 | Fork width | e | 150 | 150 | mm | |
| 5 | Lift Height(Min) | h | 80 | 80 | mm | |
| 6 | Lift Height(Max) | h1 | 200 | 200 | mm | |
| 7 | Tyre size (steering wheel) | φ180×65 | φ180×65 | mm | ||
| 8 | Tyre size (Bearing wheel) | Single Wheel | φ78×100 | φ78×100 | mm | |
| 9 | Tyre size (Bearing wheel) | Double Wheel | φ78×70 | φ78×70 | mm | |
| 10 | Weight | 75 | 68 | kg | ||
Small body and light weight High quality Pump With overload automatic unloading device, and full-load descending speed limit device Molded production, moderate price, stable quality; high-strength polyurethane wheels is stable, flexible, light, and free of magnetic fields and sparks;
